HD35EDLNTV Temperature wireless data logger Senseca

Các ứng dụng điển hình:

• Thực phẩm và Kho hàng
• Dược phẩm, Phòng thí nghiệm y tế, Phòng sạch
• Bảo tàng, Tòa nhà và Nơi công cộng
• Máy điều hòa không khí
• Năng lượng tái tạo
• Nông nghiệp và nhà kính
• Khí tượng và Thủy văn
• Quy trình công nghiệp

Hệ thống bao gồm các thành phần sau:

• HD35AP … đơn vị cơ bản
• HD35RE … bộ lặp
• H D35ED. .. dòng máy ghi dữ liệu
• Thiết bị báo động từ xa HD35ED-ALM

LIST CODE

1 100% Germany Origin

Senseca (GHM/ Honsberg) Vietnam

Model: MR1K-020GM020

Flow Switch

Indicator options: Without mechanical indicator

Nominal diameter: DN 20 – G ¾

Connection type: Female thread

Connection material: Brass nickel-plated

Pressure resistance: PN 200

Seals: NBR

Media temperature: -20 … +120 °C

Ambient temperature: -20 … +70 °C

Switching range H2O: 2 … 20 l/min H2O

Switching head: Plastic, flat head

Adjustment: Oblong hole

Electrical connection: Plug DIN 43650-A / ISO 4400

Electrical contact: Reed switch

Max. contact load: 120 V AC 0,18 A 5 VA / 175 V DC 0,25 A 5 W

Connection diagram: Changeover, connection diagram no. 0.213

Protection type: IP65

Flow direction: Horizontal from the left

2 100% Germany Origin

Senseca (GHM/ Honsberg) Vietnam

Model: MR1K-025GM030

Flow Switch

Indicator options: Without mechanical indicator

Nominal diameter: DN 25 – G 1

Connection type: Female thread

Connection material: Brass nickel-plated

Pressure resistance: PN 200

Seals: NBR

Media temperature: -20 … +120 °C

Ambient temperature: -20 … +70 °C

Switching range H2O: 3 … 30 l/min H2O

Switching head: Plastic, flat head

Adjustment: Oblong hole

Electrical connection: Plug DIN 43650-A / ISO 4400

Electrical contact: Reed switch

Max. contact load: 120 V AC 0,18 A 5 VA / 175 V DC 0,25 A 5 W

Connection diagram: Changeover, connection diagram no. 0.213

Protection type: IP65

Flow direction: Horizontal from the left

<3 jpro5 1 100% EU Origin
Grundfos Vietnam – Grundfos-Vietnam – GrundfosVietnam

Grundfos Screw spindle pump Vietnam – Grundfos Screw Pump Vietnam – Grundfos Spindle Pump Viet Nam

Code: 99473075 Screw Spindle Pump

MTS20-30 R38-DQ-T 3×230/400V 50Hz 2,2kW – Screw Spindle Pump
Grundfos Screw Spindle Pump

2 100% EU Origin

Grundfos Vietnam

Code: 96511845

Kit, Shaft seal H QQVGG KB016S1 30bar

Tuychon

3 100% EU Origin

Grundfos Vietnam

COO – Certificate of origin

<3 jpro61 1 100% Italy Origin

Senseca (Delta Ohm/ GHM) Vietnam
Senseca (Delta Ohm/ GHM) Viet Nam
Senseca-(Delta Ohm/ GHM)-Vietnam

Code: HD35EDL1NTV

Temperature and humidity wireless data logger. 24,000 samples

2 100% Italy Origin

Senseca (Delta Ohm/ GHM) Vietnam

Code: HD35APR

USB + RS485 ModBusRTU + ETHERNET

Base unit for interfacing among PC and data loggers of the system. For 35 mm DIN rail. USB connection, RS485 output with MODBUS-RTU protocol and ETHERNET interface for the

cable connection to the local network; allows the use of the MODBUS TCP/IP protocol.

3 100% Italy Origin

Senseca (Delta Ohm/ GHM) Vietnam

Code: HD35EDLNTV

Temperature wireless data logger. 68,000 samples. Optional custom LCD display (option L). Fixed vertical probe with NTC10KW temperature sensor. Suitable for ambient temperature measurement.

4 100% Italy Origin

Senseca (Delta Ohm/ GHM) Vietnam

Code: HD35EDLN/1TC

Temperature wireless data logger. Optional custom LCD display (option L). M12 connector for NTC10KW temperature probes.

1 input, 68,000 samples
